Balemaster 372A-APFUM2X9291 baler

Balemaster baler,

mod. 372A-APFUM2X9291,

s/n 493004

• Type: Horizontal closed-door / closed-end manual-tie baler
• Bale Size: 30" wide × 42" high × 72" long (standard for this series)
• Feed Opening: 28" wide × 32" high
• Main Ram Cylinder: 6" bore
• Hydraulic System:
  • Main operating pressure: 1,500 PSI
  • Relief valve pressure: 1,800 PSI
  • Hydraulic pump motor: 15 HP, 3-phase, 230/460 V
  • Oil reservoir capacity: ≈100 gallons

Controls & Operation

• Tying method: Manual wire tie (typically 2 horizontal ties)
• Operating modes: Manual, Automatic, and Continuous
• Activation: LPR (light/photo-eye) sensor for automatic cycling
• Safety/Controls: Limit switches (ram retract, advance, bale length, door closed); keyed E-stop; relay logic control panel (110 V control voltage via transformer)

Physical Details

• Approximate Dimensions (baler only): 168" L × 55" W × 92" H
• Approximate Weight (baler only): 11,000 – 12,500 lbs
• Construction: Heavy-duty welded steel frame

Performance & Applications

• Typical Applications: Paper trim, shredded OCC (old corrugated cardboard), print shop waste, folding cartons, cores, and similar light-to-medium density recyclables.
• Throughput: Approximately 1–3 tons per hour (depends on material, feed method, and operator; higher when paired with pneumatic conveying).
• Ram Force (calculated): ≈42,400 lbs (based on 6" bore at 1,500 PSI).
